TOTO CST474CUFRG#01 Vespin II Toilet Code Compliance
- Meets or exceeds ASME A112.19.2/CSA B45.1
- Certifications: IAPMO(cUPC), EPA Watersense, State of Massachusetts, City of Los Angeles, and others
- Code Compliance: UPC, IPC, NSPC, NPC Canada, and others
- Legislative Compliance: California AB715, California Green Building Code, City of Los Angeles Water Efficiency Ordinance
- ADA compliant (when installed with trip lever located on the approach side)
TOTO CST474CUFRG#01 Vespin II Toilet Specifications
| Toilet Type | Two-Piece Toilet |
| Seat Included | No |
| Toilet Bowl Shape | Elongated |
| Toilet Finish | White |
| Flush Type | Gravity Flush, Single Flush |
| Toilet Style | Modern |
| Installation Type | Floor Mounted |
| Rough-in Size | 12 in |
| Flush Lever Location | Right side |
| Gallons per Flush | 1.0 gpf |
| Toilet Length | 28 1/2 in |
| Toilet Width | 16 1/2 in |
| Toilet Height | 30 in |
| Bowl Height | 16 1/8 in |
| Toilet Material | Vitreous China |
| Trap Diameter | 2 1/8 in |
| Trapseal | 2 1/8 in |
| ADA Compliant | Yes |
| High Efficiency / Eco friendly | Yes |
| WaterSense Certified | Yes |
| cUPC Certified | Yes |
| Items Included | Toilet Bowl, Tank, Trip Lever, Drain w/trap |
| Warranty | 1 Year Limited Warranty |
TOTO CST474CUFRG#01 Vespin II Two-Piece Ultra-High Efficiency 1.0 GPF Toilet with Right Side Lever
Free Shipping!
FAQ
• What if I receive my order damaged?
While we take great care in the packaging and handling of all orders, certain circumstances during transit may be beyond our control. We ask that customers inspect all shipments within 48 hours of delivery, and in the rare event that your order arrives damaged, please send us an email with a photo depicting the damages (so we can file a claim with the carrier), and let us know whether you prefer a free replacement or a full refund.
• What if I need to return the item I purchased?
We’re happy to accommodate returns within 30 days of receiving your order. Please be aware that return shipping costs are the responsibility of the customer unless the item received is incorrect, defective, or damaged during transit. To initiate a return, simply send us an email detailing the item(s) you wish to return, and we’ll guide you through the steps.
• Why do you collect phone numbers?
Some shipping carriers, particularly those handling freight deliveries, require a phone number to coordinate your delivery. We respect your privacy and want to assure you that your phone number, or any other information you provide, will never be shared with third parties — except when expressly required by the carrier to facilitate delivery arrangements.
The TOTO Vespin II Two-Piece Elongated 1.0 GPF Universal Height skirted toilet features a sleek high profile two-piece design with elongated bowl with CeFiONtect and our powerful Tornado Flush flushing system.
Seat not included
The Vespin II bowl and tank set includes tank to bowl hardware, a tank to bowl gasket, toilet bolt caps, and unifit outlet connection for 12" rough-in. The skirted design of the Vespin II conceals the trapway, which enhances the elegant look of the toilet and adds an additional level of sophistication.
Skirted design toilets also minimize the need to reach behind the bowl to clean the nooks and crannies of the exterior trapway. The Vespin II HET employs our Double Cyclone Technology, which siphons water with two powerful nozzles, harnessing the power of water and gravity to maximize cleaning and use water more efficiently.
Meets WaterSense and CalGreen standards. ADA compliant.
The skirted design, available in many modern TOTO toilet collections, offers clean lines, minimal flourishes and geometric precision. This style is elegant and smooth, concealing the trapway, and features a base that is easy to clean and maintain.
The Tornado Flush features two powerful nozzles that create a centrifugal, cyclonic rinsing action which reduces waste buildup and keeps the bowl cleaner. Using only 1 gallon per flush, this ultra high-efficiency system is more effective in one flush than most toilets are with multiple flushes. The modern hole-free rim design means that it performs more consistently and is easy to clean.
- Dual-nozzle water propulsion system
- More powerful flush
- Cleaner bowl and less cleaning
TOTO CST474CUFRG#01 Vespin II Toilet Features
- Vitreous china construction
- Floor mount installation
- Water Use: 1.0 GPF
- Rough-In: 12" Unifit
- Chrome trip lever
- Universal Height
- Elongated front bowl and tank set
- Minimum Water Pressure: 8 PSI
- Tornado Flush system, low consumption
- CeFiONtect Ceramic Glaze: It prevents debris and mold from sticking to ceramic surfaces, leading to fewer chemicals and less water in cleaning
TOTO CST474CUFRG#01 Vespin II Toilet Documentation
Installation Manual - CST474CUFRG#01
Spare Parts Manual - CST474CUFRG#01
CAD Drawing - CST474CUFRG#01
Spec Sheet - CST474CUFRG#01
Click here for the TOTO Washlet compatibility chart
