The toilet is designed in TOTO's Universal Height, which allows for a more comfortable seat position across a wider range of users. Equipped with a left-hand chrome trip lever, and is ADA compliant.
Includes a tank to bowl gasket, tank to bowl hardware, and toilet bolt caps.
TOTO CST775CSF#51 Drake Two-Piece Toilet Specifications
- Water Use: 1.6 GPF (6.0 LPF)
- Minimum Water Pressure: 8 psi (flowing)
- Water Surface: 9" x 6-7/8"
- Trap Diameter: 2-1/8"
- Rough-in: 12"
- Trap Seal: 2-1/8"
- Warranty: manufacturer's 1 year limited
- Material: Vitreous China
- Meets and exceeds ASME A112.19.2/CSA B45.1
- Certifications: IAPMO(cUPC)
- Code Compliance: UPC, IPC, NSPC, NPC Canada, and others
- ADA compliant (when installed with trip lever located on the approach side)
- Seat sold separately
- Finish: Black/Ebony
TOTO CST775CSF#51 Drake Two-Piece Black Rounded Toilet with 1.6 GPF Tornado Flush, Ebony Finish
Free Shipping!
FAQ
• What if I receive my order damaged?
While we take great care in the packaging and handling of all orders, certain circumstances during transit may be beyond our control. We ask that customers inspect all shipments within 48 hours of delivery, and in the rare event that your order arrives damaged, please send us an email with a photo depicting the damages (so we can file a claim with the carrier), and let us know whether you prefer a free replacement or a full refund.
• What if I need to return the item I purchased?
We’re happy to accommodate returns within 30 days of receiving your order. Please be aware that return shipping costs are the responsibility of the customer unless the item received is incorrect, defective, or damaged during transit. To initiate a return, simply send us an email detailing the item(s) you wish to return, and we’ll guide you through the steps.
• Why do you collect phone numbers?
Some shipping carriers, particularly those handling freight deliveries, require a phone number to coordinate your delivery. We respect your privacy and want to assure you that your phone number, or any other information you provide, will never be shared with third parties — except when expressly required by the carrier to facilitate delivery arrangements.
This TOTO Drake two-piece rounded toilet from the updated 2021 Drake collection with Tornado Flush is a masterfully designed high quality water-saving toilet. Designed with quality materials to ensure longevity and durability, this toilet features TOTO's Tornado Flush technology - a rimless, hole-free design with dual-nozzles that create a strong centrifugal washing action which rinses the bowl much more efficiently than traditional flushing mechanisms.
Additional items needed for installation and use must be purchased separately: wax ring, toilet mounting bolts, water supply lines, and toilet seat.
Improved Water Spot: a large water spot reduces the places where waste can cling to the bowl.ADA Compliant: to serve the needs of everyone without the need for additional adaptation from the user. Universal Height is taller than a standard toilet and makes sitting down and standing up easier for many people.
Sustainability: the 1.6 gallon per flush Drake enables you to save water without worrying about diminished performance. The Drake features a wide 3 inch flush valve and a siphon jet bowl that gets the job done in one flush.
Human Centered Design: upgrade your bathroom with this stylish design that works really well with any bathroom decor. The rounded bowl saves space by not protruding as far as an elongated one. The toilet fits into 12 inch rough-in installations and has a left-hand trip lever.
Complete the Package: complete your toilet ensemble with the addition of a TOTO SoftClose seat, or upgrade to a WASHLET bidet seat. Drake tank and bowl with hardware included. Purchased Separately: Wax ring, flange bolts, and water supply lines.
TOTO CST775CSF#51 Drake Two-Piece Toilet Documentation
-
Installation Manual - CST775CSFG
Spare Parts Manual - CST775CSFG
CAD Drawing - CST775CSF(G)
Spec Sheet - CST775CSF(G)
Click here for the TOTO Washlet compatibility chart
