TOTO TES204AJi#CP Commercial Soap Dispenser with Controller Features and Benefits
- Automatically dispenses measured application of foam soap
- Smart sensor with aerated flow
- Two spout connection
- 0.8 gallon (3 liter) tank reservoir and 5.3 gallon (20 liter) subtank
- Product requires communication card sold separately to enable IoT functionality
- ADA Compliant
- 55 inch power cord (requires 120V AC power supply)
- Includes controller base unit, reservoir tank, subtank, two spouts, mounting hardware and supply lines
- Purchase separately: Required TOTO Soap.
TOTO TES204AJi#CP Commercial Soap Dispenser with Controller Specifications
- Color: Polished Chrome
- Warranty: Manufacturer Three Year Limited
- Made in Japan
- Material: Brass
- Component #1 Model: TLK07001G#CP
- Component #2 Model: TLK01106Ui
- Component #3 Model: TLK01401U
- Item Length (in.): 5.5
- Item Width (in.): 1.5625
- Item Height (in.): 3
- Item Weight (lb.): 29.31345
- Reach (in.): 4.3125
- Spout Height (in.): 2.5
- ADA Compliant: Yes
- Installation: Single-Hole
- Valve Included: Yes
- Mounting Type: Deck-Mount
- Faucet Holes Required: 1
- Maximum Deck Thickness (in.): 1.125
TOTO TES204AJi#CP Commercial Soap Dispenser with Controller Downloads and Documentation
TOTO TES204AJi#CP Touchless Auto Foam Soap Dispenser Controller, IoT-Ready, Polished Chrome
Frequently Asked Questions
• What's the difference between IoT-Ready and IoT-Enabled?
IoT-Ready means the product is built to work with TOTO's smart-monitoring system but needs a separately-sold communication card to activate. IoT-Enabled comes with the card already installed and ready to connect. Both perform the same core functions - the IoT module adds remote usage tracking, maintenance alerts, and diagnostic data for facility managers.
• Does ECOPOWER need batteries or external power?
No batteries and no wiring. ECOPOWER generates its own electricity from the force of water flowing through the controller each time it activates, then stores it for the next use. That's why commercial facilities prefer ECOPOWER - no battery replacement schedule and no electrician needed for installation.
• Why 2 spouts on this model?
This dispenser has 2 integrated spouts - pick the variant that matches the number of sink stations in your restroom. The 2-spout version reduces the count of separate dispensers users see on the counter and simplifies maintenance.
• What's the subtank for?
The 20-liter subtank dramatically extends the time between refills - it feeds the main reservoir automatically when soap runs low. Especially useful in high-traffic restrooms where standard 3-liter reservoirs need refilling weekly. Cuts maintenance trips significantly.
• Will it work with any liquid or foam soap?
Designed for TOTO's compatible foam soap formula - using standard liquid hand soaps can clog the foaming mechanism. Most facility-supply companies sell compatible foam soap concentrates that work with these dispensers and meet the same hygiene standards as commercial hand-soap programs.
TOTO soap dispensers offer automatic, touchless operation. IoT-Ready: Product requires communication card sold separately to enable IoT functionality. The hands-free function dispenses soap without contact.
The self-adjusting sensor on the spout detects the user's hand to automatically dispense a controlled amount of foam soap. The 3 liter (.08 gallon) reservoir and controller is designed to connect with two chrome plated spouts. The large 20 liter (5.3 gallon) sub-tank helps minimize frequent refills and helps ensure proper function of the soap dispenser.
Includes controller base unit with 3 liter (0.8 gallon) reservoir, 20 liter (5.3 gallon) subtank with 16.4 ft. connection hose, two chrome plated spouts, mounting hardware and supply lines. TOTO soap is required for proper functionality and is sold separately.
TOTO TES204AJi#CP Commercial Soap Dispenser with Controller UPC Code: 739268996212.
